HETRONIC BMS-2 VC - Page 10

8
Figure 2: BMS-2 Components (PWM)
Table 2: BMS-2 Components (PWM)
1 70 Pin Connector (X1) 12 TTL Digital Outputs (X7)
2 Fuse (7.5Amp) 13 Antenna
3 External Inputs 14 Address Module (Stop Decoder)
4 2-Pin Connector (output) 15 Address Module (Main Decoder)
5 RS232 Interface 16 CAN Termination (X2)
6 Terminal Block 17 CAN Interface (X3)
7 RF Module (A2) 18 Status Indicator
8 Green LED (X14) 19 Mounting Screw Recesses
9 Transmitter OFF Connection (X15) 20 Common YO/Stop Output
10 Transmitter Feedback (X13) 21 Cable Control/Programming Port (X2)
11 Receiver RF Module Connection (X11)
BMS-2: S
y
stem Status Indicators
y
x x 0 - Normal
Op
eratio
n
x x 1 -
S
ystem Not
S
tarte
d
x x
3
-
Co
mm
u
ni
cat
i
o
n Err
or
x x 2 - Active E-Sto
p
x x 4 - Passive E-Sto
p
x x x . - Dot blinks = Tel
g
ram O
K
x x . x - Dot on = Pro
g
ram Mod
e
E
x x - Err
o
r
Code
1
x x - Analo
g
Channel 1 activ
e
2
x x - Analo
g
Channel 2 activ
e
www.
h
etron
i
c.co
m
... up to Analog
C
hannel 8
1
2
1
2
6
7
11
12
13
14
15
19
3
4
5
8
9
10
16
17
18
21
20
X18
X2
X3
X14
X15
X13
X11
X17
