Hexagon ROMER Absolute Arm - E.9 Quindos7

Configuration for end-software
ROMER ABSOLUTE ARM Manual V2.3.1 (29/05/2012) 56
E
QUINDOS7
E.9
Configuration for probing E.9.1
Upon Quindos/IppServer-startup the configuration menu is shown for arm settings, (for example
the speaker volume). To make the new settings effective, press the SAVE-button and exit the
configuration menu.
Buttons :
Probing scan
Only scanning of unknown contours is currently implemented.
The result points are sent to Quindos at the end of the scan or when a certain amount of points
are measured
Scanning ends when a point is reached that fulfils the stop condition
Scanning also ends, when the red (main) button is released. This feature can be switched on
and off with the registry entry “EndScanOnButtonUp” in the “Driver”-section of the working
environment.
Probe naming:
The probe names in Quindos and RDS will differ due to different naming conventions:
RDS:
“Center reference probe”,
“6mm”,
“3mm”
Quindos:
“_Center_reference_probe”,
“_6mm”,
“_3mm”
(The name conversion is automatic)
Probe calibration:
If recalibration is needed, the user can execute the Quindos command ReQualifyTool; for
detailled usage of the command , please see the Quindos user manual.
Please avoid renaming of probes during calibration. Use the predefined names !
Button
Short click
Long Click
Left (0)
Equivalent to POS-button on Leitz
jogbox
DELR (delete record)
Main (1)
Take a probing point
Take burst probing points until released
Right (2)
Execute actual line
END (Execute all following lines up to the
end of the list)
