Measure with the arm
ROMER ABSOLUTE ARM Manual V2.3.1 (29/05/2012) 83
HOW TO INTERPRET THE ARM SOUNDS F.6
When taking points, validating features, or performing other operations with the arm, the arm
emits sounds.
Low-pitch sounds usually mean cancel, go back, down, or delete. High-pitch sounds usually
mean validate, go forward, up, or complete. Many sounds are context sensitive and will become
more familiar to the user with daily use.
The volume can be controlled from RDS control Panel.
An external speaker or earphone can be added for more volume, through the 3.5mm audio jack
the arm base.
HOW TO DO ACCURACY VERIFICATION / CALIBRATION F.7
RDS Data Collector has multiple “Quick-check” procedures the user can perform to verify arm
and accessories accuracy, and calibration. It also has full certification procedures such as the
B89.
Please refer to RDS Data Collector manual for full descriptions of each procedure..
