17
The borders are displayed on the bottom of the screen after loading the graphic. (Menu
item Graphic)
The Symbols
(A) Auto
(C) From calibration curve
(M) Manually
represent the selected indicating range.
The borders are displayed only when the "Grid" is enabled.
5. Colour profile
A colour profile for the display of a measurement array in "false colours” can be
selected here. These profiles correspond with the profiles in the software
MOISTANALYZE.
6. Grid
With this you can overlay a grid over the graphic. The intersection points show the
measurement points in the measurement area. The statistic values and the display
range are only displayed on the bottom of the screen if the “Grid” is activated.
4.2.2.3 Edit note
Every measuring field have text field where a shot note can be added. The text have a
maximum length of 24 characters. To edit the note use the following buttons:
Press the arrow buttons <
←> or <→> to select the character. To confirm the character
press the <ENTER> button.
To select a position of the cursor in the note press the < <Pos> button or <Pos> >
button.
The symbol
< in on the virtual keyboard is used as a backspace key to delete
inadvertently entered characters. Confirmation by <ENTER> button.
The symbol in the virtual keyboard is used to insert spaces in the note. Confirmation
by <ENTER> button.
The text is saved after pressing <ESC> button and can be edited later in the software
MOISTANALYZE. In the software, the limitation to 24 characters is repealed.
