Identify Device (ECh)
The Identify Device command transfers 512 bytes of data that specify the drive’s parameters. Table 5-8 lists
the parameters read by the host
Table 13 Identify Device Command
WORD FIELD DESCRIPTION
POWER-ON DEFAULT
VALUE
0 General Configuration 427Ah
1 Obsolete 3FFFh
2 Specific Configuration C837h
3 Obsolete 0010h
4-5 Retired 0000h
6 Obsolete 003Fh
7-8 Reserved for assignment by the CompactFlash™ Association 0000h
9 Retired 0000h
10-19 Serial Number (ATA String) nnnnnnnn
20-21 Retired 0000h
22 Obsolete 0000h
23-26 Firmware Revision (ATA String) “nnnnnnn”
27-46 Model Numbers (ATA String)
“HGST HUS722T2TALA604”
“HGST HUS722T1TALA604”
47 READ/WRITE MULTIPLE
support Bit 15-8: 80h
Bit 7-0: 00h: Reserved
01h-FFh = Maximum number of logical sectors that shall
be transferred per DRQ data block on READ/WRITE
MULTIPLE commands
8010h
48 Trusted Computing feature set
options Bit 15: Shall be cleared to
zero
Bit 14: Shall be set to one
Bit 13-1: Reserved for the Trusted Computing Group
Bit 0: If set, Trusted Computing feature set is
supported
4000h
49 Capabilities
Bit 15-14: Reserved for the IDENTIFY PACKET
DEVICE command.
Bit 13: If set, Standby timer values as specified in
this standard are supported.
0 = Standby timer values shall be managed by the
device Bit 12: Reserved for the IDENTIFY PACKET
DEVICE command
Bit 11: If set, IORDY supported
Bit 10: If set, IORDY may be
disabled Bit 9: If set, LBA supported
Bit 8: If set, DMA supported
Bit 7-2: Reserved
Bit 1: Current Long Physical Alignment Setting
2F00h
50 Capabilities
Bit 15: Shall be cleared to zero.
Bit 14: Shall be set to one.
Bit 13-2: Reserved.
Bit 1: Obsolete
Bit 0: Shall be set to one to indicate a device
specific Standby timer value minimum
4001h
51-52 Obsolete 0000h
