HGST Ultrastar 7K2 User Manual

Ultrastar 7K2
HGST Hard Disk Drive
Technical Reference Manual
36
370 01h
Error logging capability. Bits are as follows:
0
1 = Error logging supported
1
Reserved
371 XX
Reserved
372 XX
Short self-test routine completion time in minutes
373 XX
Extended self-test routine completion time in minutes
374 XX
Conveyance self-test routine completion time in minutes
375 - 510 XX
Reserved
511 XX
Checksum
Supported Attributes
The drive supports the following attributes.
Table 11 Supported Attributes
Attribute
A
ttribute ID Number Pre-Failure/Advisory Bit
(Status Flags bit 0)
1
Read Error Rate 1 Pre-Failure
Spin-up Time 3 Pre-Failure
Start/Stop Count 4 Advisory
Re-allocated Sector Count 5 Pre-Failure
Seek Error Rate 7 Advisory
Power-on Hours Count 9 Advisory
Spin-up Retry Count 10 Advisory
Drive Calibration Retry Count 11 Advisory
Drive Power Cycle Count 12 Advisory
Gas Gauge 16 Advisory
Emergency Retract Cycles 192 Advisory
Load/Unload Cycles 193 Advisory
HDA Temperature
2
194 Advisory
Relocation Event Count 196 Advisory
Current Pending Sector Count 197 Advisory
Offline Scan Uncorrectable Sector Count 198 Advisory
Ultra DMA CRC Error Rate 199 Advisory
Multi-zone Error Rate 200 Advisory
1
Status bits are typical but may vary.
2
See “Temperature Reporting” on page 24 for a better mechanism.
Attributes that use the Pre-Failure/Advisory Bit Set can predict potential future degrading or faulty
conditions. Attributes with the Failure/Advisory Bit Clear are used for informational purposes only, they
do not indicate impending drive failure.
The S.M.A.R.T. data saving process is a background task. After a pre-determined idle period, the self-
monitoring data is automatically saved to the disk.
