vRTK GNSS System User Manual
9
2. Static mode:
Sampling interval >1s: flashes at the sampling interval.
Sampling interval ≤1s: flashes once per second.
1. RTK mode: no correction data.
2. Static mode: sampling has not started.
The satellite is tracked.
The satellite is not tracked.
2.3 WEB management system
The vRTK unit has a built-in web management system that can be used to set the receiver's working
mode and data output, as well as viewing receiver and satellite information. The receiver’s Wi-Fi name
is its S/N. You can connect it to a controller or phone (the default password is 12345678) inputting the
IP address 192.168.20.1 into the browser to log in.
Note: The web management system can only be visited when the receiver’s Bluetooth isn’t connected.
2.3.1 Main Menu
After logging into the web management system, you click ‘Start’ to enter the main menu where each
option contains drop-down menus.
Figure 2-3-1 Home Figure 2-3-2 Main menu
