August 2005 Page 3 of 23
2005 © HID Corporation. All rights reserved.
VertX V2000 (CS) Quick Installation Guide
Introduction
VertX™ CS is the first family of access controllers designed specifically for alarm dealers for direct
connection to central stations. Because it was designed with central station in mind, VertX CS works with
software from leading central station automation providers, including Bold Technologies, DICE and
GE MAS.
The V2000 is designed to control two sets of door devices (such as two-doors, two-readers, associated
contacts and relays) as well as manage communications with the central station automated software.
Parts List
Description Quantity
VertX™ V2000 Reader Interface/Access Controller
Note: The V2000 controller has a plastic base and is covered
with a Plastic or Mylar cover.
1
- Lithium Battery 1
- Mounting screws 4
- 2.2K EOL resistors 8
- Quick Installation Guide 1
- Installation Wiring Diagram Example 1
Product Specifications
Description Specification
Power Supply 12-16VDC
Maximum current at 12VDC per V2000 1 Amp
Average operating current at 12VDC
625 mA (with two R40 iCLASS Readers)
Operating temperature range 32°-122°F (0°-50°C)
Humidity 5% to 95% non-condensing
Cable Specifications
Cable Type Length Specification
Input Circuits * 500 feet (150 m)
2-conductor, shielded, using ALPHA 1292C (22AWG) or Alpha 2421C
(18AWG), or equivalent.
Output Circuits * 500 feet (150 m)
2-conductor, using ALPHA 1172C (22AWG) or Alpha 1897C (18AWG), or
equivalent.
Wiegand
500 feet (150 m) to reader ALPHA 1299C, 22AWG, 9-conductor, stranded, overall shield.
Fewer conductors needed if all control lines are not used.
Ethernet 328 feet (100 m) Cat5, Cat5E, and Cat6
Power Supply
+12 VDC IN
---- Refer to your Power Supply Installation Guide.
* Minimum wire gauge depends on cable length and current requirements.
