Upper case and shift lever
5. Remove the steering friction adjuster f,
and then remove the cover g and friction
piece h.
6. Remove the bushings i, j, k, and l.
7. Remove the bushing m.
Checking the upper case
1. Check the upper case. Replace if
cracked or eroded.
Installing the upper case
1. Install a new bushing a. NOTICE: Do
not reuse a bushing, always replace it
with a new one.
2. Install the bushings d and e.
e
h
g
f
i
j
l
l
k
Bushing installer center bolt n
Bushing attachment o
Pipe p (reference):
b: 12.0 mm (0.5 in)
c: 16.0 mm (0.7 in)
d: 37.0 mm (1.5 in)
Driver rod L3 b
Needle bearing attachment c
n
p
b
c
d
o
m
p
a
b
c
a
