Electrical component and wiring harness routing
Top
aEngine shut-off switch
bCDI unit
cFuse (20 A)
dLighting coil
A Fold the holders inward so that the leads
do not come out from the holders.
B Check that the ground lead does not inter-
fere with the bolt or washer.
c
b
B
a
A
d
