Section 2 - Transporting the Bale Mover
2.0 TRANSPORTING THE BALE MOVER
Only tow the Bale Mover behind a
properly sized and equipped
tractor or vehicle which exceeds
the weight of the loaded Bale
Mover by 50%.
Shut off the tractor engine before
attaching the bale mover or
hydraulics.
Do not allow children or other
people to ride on the tractor or
Bale Mover. Falling off can result
in serious injury or death.
1. Tractor Requirements
- Roll Over Protection System (ROPS)
- Working seatbelts
- 2 Spool Control Valves (SCV)
2. Adjust position of the tongue plate.
- Position the tongue plate so that the
bale mover is level when connected to
the tractor drawbar.
- Remove the bolts and move the
tongue plate. Fasten in place.
Adjust Position of the Tongue Plate
211071
Page 2-1
