Section 2 - Transporting the Bale Mover
7. Attach Hydraulic Hoses
- Clean the end of the hoses and the
connection.
- Firmly push the hoses into the tractor
receptacle according to user
preference.
- Route the hoses so they do not
interfere with moving parts.
8. Connect the lighting cable to the electrical
connection on the tractor.
9. Route the Electric Control Cable
- Route the electric control cable into
the tractor cab.
- Ensure the cable does not interfere
with or contact moving parts.
10. Place the Hitch Jack in the Storage
Location.
- Remove all weight from the jack.
- Remove the locking pin holding the
jack onto the hitch.
- Place the jack to the storage position
(1).
- Fasten the jack in place with the lock
pin.
11. Lower the Bale Mover bed.
Attach Hydraulics and Lighting
108008
Jack in the Storage Location
211072
Lower the Bed
211034
Page 2-3
