Section 5 - Maintaining the Bale Mover
5.0 MAINTAINING THE BALE MOVER
Shutdown Procedure
For your safety and the safety of
others, this procedure must be
followed before dismounting from
the tractor for repairing, servicing,
cleaning, or lubricating the Bale
Mover.
Step 1: Reduce the engine speed to idle.
Step 2: Fully lower left & right fork lifts.
Step 3: Disengage hydraulic motors.
Step 4: Set the tractor park brake.
Step 5: Shut off tractor engine and remove
the key.
Step 6: Relieve hydraulic pressure and
disconnect hydraulic hoses.
Lubrication
Lubricate all grease fittings with a quality
lithium complex, extreme pressure NLGI
Grade 2 grease.
Every 10 Hours
! Side Lift Arms- Lubricate 2 points on each
side lift arm every 8 hours.
- 1 point at the front pivot.
- 1 point at the rear pivot.
Grease Both Side Lift Arms
211062C
Page 5-1
