Section 4 - Operating the Bale Mover
4. Engage the bale roller chains to move the
bales forward and onto the Bale Mover
bed.
5. Slowly back up towards the bales as they
are reloading.
6. When bales are reloaded, lower the bed
completely into the operating position.
7. Crossing Ditches and Steep Inclines
- Cross ditches or inclines at about a
30° approach angle.
Engage Chains and Back Up
211056
Lower Bed When Done Reloading
211060
Cross Ditch at 30° Angle
107072
Page 4-10
