Section 4 - Operating the Bale Mover
RELOADING BALES
Bales can be reloaded from the bale row
onto the Bale Mover.
1. The Control Switch in the tractor cab
enables the hydraulic remotes to control
the bed tilt and the bale roller chains.
- Center the electric rocker switch.
- Use one tractor remote to tilt the
bed to the reload position.
- Use the other tractor remote to
operate the roller chains to push
the bales forward onto the deck.
2. Position the Bale Mover to reload the
bales from the storage location.
3. Tilt the bed to the fully raised position.
Tilt and Reload Position
211054
Position to Reload Bales
211058
Tilt Bed to Fully Raised Position
211059
Page 4-9
