Section 3 - Bale Mover Preparation
Check Condition of the Bale Chains
211037
5. Check the Condition of the Bale Chains
- Clean debris and material buildup
from the chain area and the chain
channels.
- Check that no wire or other materials
are wrapped in the chain.
- Check that the chain is secure around
the end roller.
- Check the tension on all the chains.
- The chain can be seen in the sight
hole (1) that is in the side of the
rail.
- The chain should be in line with
the image of the chain that is on
the decal at the sight hole.
- Adjust as necessary. See “Chain
Adjustment Procedure” in the
Maintenance Section.
Check Tension of All the Chains
211061
Check That The Chain Is On The End Roller
211038
Chain Tension
E7567_A
Page 3-2
