Section 2 - Transporting the Bale Mover
12. Check the condition of all the tires.
- Ensure that the lug nuts have the
cone side of the lug nut against the
wheel rim.
- Torque the lug nuts to 170 lbf (230
Nm).
- Fill the tires to 90 psi (620 Kpa).
13. Raise both bale lift arms.
14. Install the lift arms transport lock
chains (1) on both arms.
- Install the chain pins (2) and clip into
place with the spring pins.
Always use fork transport chains
when transporting Bale Mover on
public road ways. Forks may
descend rapidly if hydraulic
pressure is lost to a lift cylinder.
Tires
107094CC
Install Transport Lock Chains
211036C
Page 2-4
