Section 4 - Operating the Bale Mover
4.0 OPERATING THE BALE MOVER
Do Not Allow Anyone to Ride on
the Bale Mover.
- Falling from the machine can
cause injury
Stay clear of overhead power
lines. Electrocution can occur
without contacting the power
lines.
1. Park on Level Ground
2. Remove the lift arm transport chains on
both arms.
Note: Do not lower the lift arm when
transport chains are in position or
damage to the machine will occur.
- Raise lift arms to remove tension on
the transport chain.
- Remove the clip pin (2) and remove
the chain pin (1).
- Place the chain pin (1) back into the
tabs and lock in place with the clip pin
(2).
Remove Arm Transport Chains
201118C
Page 4-1
