Section 4 - Operating the Bale Mover
UNLOADING BALES
1. The Control Switch in the tractor cab
enables the hydraulic remotes to control
the bed tilt and the bale roller chains.
- Center the electric rocker switch.
- Use one tractor remote to tilt the
bed to the unload position.
- Use the other tractor remote to
operate the roller chains to push
the bales back and slide them off
of the deck.
2. Position the Bale Mover to unload the
bales in the storage location.
3. Tilt the bed to the fully raised position.
Bed Tilt and Unload
211054
Position in the Storage Location
211055
Tilt Bed to Fully Raised Position
211050
Page 4-7
