Section 7 - Specifications
7.0 BALE MOVER SPECIFICATIONS
Shipping Weight 9,660 lbs (4,382 kg)
Hitch Weight (empty) 1,740 lbs (789 kg)
Hitch Weight (Loaded) 3,423 lbs (1,553 kg)
Hitch Weight (Partially loaded - worst
case)
5,576 lbs (2529 kg)
GVW 38,000 lbs (17,236 kg)
Total Length 43’ 9¼” (13.34 m)
Bed Length 37’ (11.28 m)
Total Width (Loaded) 16’8”’ (5.08 m)
Total Width (Unloaded) 15' 1½" (4.61 m)
Bed Width 11’2” (3.4 m)
Total Height (Max) 12’ 3¼” (3.74 m)
Bed Height 3’3” (991 mm)
Maximum Capacity 16 of 4' long bales
14 of 5' long bales
Total bale weight - 23720 lb (10759 kg)
Tires 11L-15FI, F Ply
Horsepower Required 100 hp (75 kW)
Hydraulic Outlets 2
Hydraulic Pressure 2,500 psi. (17237 KPa)
Page 7-1
