HighLine RCH Mower - Troubleshooting Driveline Tube, Yoke, and Bent PTO Issues

Section 7 - Troubleshooting
Page 7-8
Drivelines
Symptom Problem Solution
Telescoping Tube Fails Shock load Avoid solid objects
Collapsed beyond allowed
angle
Avoid such conditions
Set the drawbar to the
proper length
Replace driveline
Yoke or cross fails Lack of lubrication Apply grease
Shock load Avoid solid objects
Slip clutch seized causing
driveline to receive high
shock load
Inspect clutch lining and
replace. Use Highline parts
Twisted Slip clutch seized causing
driveline to receive high
shock loads
Inspect clutch lining and
replace as necessary. Use
Highline parts
PTO Driveline Bent Contact with the drawbar Reposition drawbar. Refer to
“Transporting the Mower”
Section
Driveline too long, bottoms
out when operating through
deep ditches
Avoid these conditions
