HSL KM Switch Quick Setup Guide
INSTALLATION
SECTIONS
Table of Contents
1 32
Step 4 – What are presets?
• Presets reflect the layout and boarders of
computer displays to the KM.
Presets allow:
• Support of various display layouts. Align
displays vertically (on top) and Horizontally
(along side).
• Associate the mouse cursor with each
computer based on its respective display
position.
• Consider all displays as one absolute screen area to allow VDT.
• Virtual Display Technology (VDT) - Switch control between PCs
by moving the mouse cursor across display boarders (all over the
absolute screen area).
F11 | F1
1 2
3 4
F11 | F2
1 2 3 4
F11 | F3
1P 1S
3P 3S
F11 | F4
1P 3P
1S 3S
F11 | F5
1 2 3P 3S
F11 | F6
1 2P 2S 4
F11 | F7
1P 1S 3 4
F11 | F8
1P 1S 3P 3S
F11 | F9
1 2 3
F11 | F10
1
2 3 4
(Factory
Default)
F11 | 1 | 1
1
2
3
F11 | 1 | 2
1
2 3
F11 | 1 | 3
1
2 3
F11 | 1 | 4
1 2
3
F11 | 1 | 5
1 2
3
F11 | 1 | 6
1
2 3 4
F11 | 1 | 7
1
2 3 4
F11 | 1 | 8
1 2 3
4
F11 | 1 | 9
1 2
3P 3S
F11 | 1 | 0
3P 3S
1 2
F11 | 2 | 1
1 3P
2 3S
F11 | 2 | 2
3P 1
3S 2
F11 | 2 | 3
2 3 4
1P 1S
F11 | 2 | 4
3P
3S 1P 1S 3
F11 | 2 | 5
1
2
F11 | 2 | 6
1 2
F11 | 2 | 7
1 2
3
F11 | 2 | 8
3
1 2
F11 | 2 | 9
1
2
3
F11 | 2 | 0
1
3
2
F11 | 3 | 1
2P
2S 1P 1S 3
F11 | 3 | 2
1 2 3 4 5 6 7 8
F11 | 3 | 3
(8-Port Only)
5 6 7 8
1 2 3 4
F11 | 3 | 4
(8-Port Only)
1 2 3 4 5
F11 | 3 | 5
(8-Port Only)
5 6
1 2 3 4
F11 | 3 | 6
(8-Port Only)
4 5 6
1 2 3
F11 | 3 | 7
(8-Port Only)
1P
1S 2 3 4 5
F11 | 3 | 8
(8-Port Only)
1 2 3 4
5 6
F11 | 3 | 9
(8-Port Only)
1 2 3 4 5 6 7
F11 | 3 | 0
(8-Port Only)
6 7 8
1 2 3 4 5
Preset #1 (Default)
Preset #2
Absolute Mouse-Screen area
