Hikmicro OWL Series User Manual

Thermal Monocular User Manual
19
Figure 5-2 Start Recording
The left top of image displays the information of recording time.
2. Hold again to stop recording.
What to do next
For exporting recording files, refer to Export Files.
5.5 Hot Tracking
The device can detect the highest temperature spot in the scene and mark it on display.
Steps
1. Hold to show the menu.
2. Select , and press to mark the spot of highest temperature.
Result
When the function is enabled, displays in the spot of highest temperature. When the scene
changes, the moves.
Figure 5-3 Hot Tracking

Hikmicro OWL Series Specifications

General

Aperture	F1.0
Record Video	Yes
Capture Snapshot	Yes
Wi-Fi	Yes
Lens	19 mm
Detector Type	Uncooled VOx microbolometer
Pixel Interval	17 μm
Response Waveband	8μm - 14μm
NETD	<40mK
Digital Zoom	1 ×, 2 ×, 4 ×, 8 ×
Frame Rate	50 Hz
Battery Type	Lithium rechargeable battery
Operating Temperature	-20 °C to 55 °C (-4 °F to 131 °F)
Thermal Sensitivity	<40mK
