HIKVISION 7604NI-K1B User Manual

Network Video Recorder User Manual
227
Chapter 14 HDD Management
14.1 Initializing HDDs
Purpose:
A newly installed hard disk drive (HDD) must be initialized before it can be used with your NVR.
A message box pops up when the NVR starts up if there exits any uninitialized HDD.
Figure 14-1 Message Box of Uninitialized HDD
Click Yes button to initialize it immediately or you can perform the following steps to initialize the
HDD.
Step 2 Enter the HDD Information interface.
Menu > HDD> General
Figure 14-2 HDD Information Interface
Step 3 Select HDD to be initialized.
Step 4 Click the Init button.
Figure 14-3 Confirm Initialization

HIKVISION 7604NI-K1B Specifications

General

Model	7604NI-K1B
HDMI Output Resolution	4K (3840 × 2160)
VGA Output Resolution	1920 × 1080
Decoding Format	H.265+/H.265/H.264+/H.264
Video Compression	H.265+/H.265/H.264+/H.264
Max Incoming Bandwidth	40 Mbps
HDD Bays	1
Storage Interface	SATA
Max HDD Capacity	6TB
Max Storage Capacity	6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC, 1.5 A
Consumption	≤ 10 W (without HDD)
Operating Humidity	10% to 90%
Synchronous Playback	4-ch
Type	NVR
Channel Capacity	4
Network Protocol	TCP/IP, DHCP, DNS, DDNS, NTP, UPnP
Network Interface	1 × RJ-45 10/100/1000 Mbps
Working Temperature	-10°C to +55°C (14°F to 131°F)
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Video Output	1 × VGA, 1 × HDMI
