IR Speed Dome User Manual
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
menus, you can set them to “OFF”.
DISPLAY SETUP
!! ZOOM DISPLAY OFF
PT DISPLAY OFF
TIME DISPLAY OFF
PRESET DISPLAY OFF
HEATFAN DISPLAYOFF
BACK EXIT
Figure 3-5 Display Setup
3.2.2 Configuring the Camera Settings
Note:
The menu operation interface of the different model of speed dome may differ. Please refer to the
actual operation interface.
You can configure the Focus, Shutter, White Balance and Noise Reduce, etc. on the OSD menu. See
Figure 3-6.
CAMERA SETUP
!! FOCUS HAF
ZOOM LIMIT 23
ZOOM SPEED HIGH
SLOW SHUTTER N/A
IRCUT FILTER DAY
D/N LEVEL 1
SHAPNESS 8
BACK EXIT
CAMERA SETUP
AE MODE AUTO
IRIS N/A
SHUTTER 50
GAIN 1
EXPOSURE COMP 7
WHITE BALAN AUTO
IMAGE FLIP N/A
!! BACK EXIT
CAMERA SETUP
FOCUS LIMIT 1M
INIT LENS OFF
NOISE REDUCE ON
HR MODE ON
CONTRAST 2
SATURATION 3
!! BACK EXIT
Figure 3-6 Camera Setup
Focus Settings
Steps:
(1) Move the cursor to FOCUS using the direction buttons and click IRIS+ to enter.
(2) Click up/down direction buttons to choose the focus mode as AF, MF or HAF.
AF (Auto-focus): The lens remains in focus during PTZ movements.
MF (Manual Focus): Lens focus is adjusted manually.
HAF (Half-auto Focus): The lens remains at a fixed focus point when PTZ movements stop;
when the PTZ movements are resumed, the lens focuses automatically. It is the default focus
mode.
(3) Click IRIS+ button to confirm.
Zoom Limit Settings
Purpose:
To Next Page
