HIKVISION DS-2CD2012-I User Manual

User Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
76
Section 5.6.4.
 Record Triggered by Motion & Alarm
If you select Motion & Alarm, the video will be recorded when the motion
and alarm are triggered at the same time.
Besides configuring the recording schedule, you have to configure the
settings on the Motion Detection and Alarm Input Settings interfaces.
Please refer to Section 5.6.1 and Section 5.6.4 for detailed information.
 Record Triggered by Motion | Alarm
If you select Motion | Alarm, the video will be recorded when the external
alarm is triggered or the motion is detected.
Besides configuring the recording schedule, you have to configure the
settings on the Motion Detection and Alarm Input Settings interfaces.
Please refer to Section 5.6.1 and Section 5.6.4 for detailed information.
 Record Triggered by PIR Alarm
If you select PIR Alarm, the video will be recorded when the PIR alarm is
detected.
Besides configuring the recording schedule, you have to set the PIR alarm
and check the checkbox of Trigger Channel in the Normal Linkage of PIR
Alarm in Other Alarm Settings interface. For detailed information, please
refer to Step 2 Configure the PIR Alarm in the Section 5.6.9.
 Record Triggered by Wireless Alarm
If you select Wireless Alarm, the video will be recorded when the wireless
alarm is detected.
Besides configuring the recording schedule, you have to set the wireless
alarm and check the checkbox of Trigger Channel in the Normal Linkage of
Wireless Alarm in Other Alarm Settings interface. For detailed information,
please refer to Step 1 Configure the Wireless Alarm in the Section 5.6.9.
 Record Triggered by Emergency Alarm
If you select Emergency Alarm, the video will be recorded when the
emergency alarm is detected.
Note: This type is for certain series camera only.
 Record Triggered by Manual Alarm
If you select Manual Alarm, the video will be recorded when manual alarm
is triggered.
 Record Triggered by PIR | Wireless | Manual
If you select PIR | Wireless | Manual, the video will be recorded when the
PIR alarm or wireless alarm or manual alarm is detected.
Besides configuring the recording schedule, you have to configure the
settings for wireless alarm and PIR alarm in Other Alarm Settings interface.
For detailed information, please refer to Section 5.6.9.
www.cctvireland.ie

HIKVISION DS-2CD2012-I Specifications

General

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Bullet
Product color	White
International Protection (IP) code	IP66
Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 960, 640 x 480 (VGA), 704 x 576
Camera shutter speed	1/25(1/30) - 1/100000 s
Minimum illumination	0.01 lx
Field of view (FOV) angle	73.1 °
Sensor type	CMOS
Optical sensor size	1/3 \
Lens diameter	4 mm
Focus adjustment	2.0
Password protection type	User
LED type	IR
Night vision distance	30 m
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	5 W
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Width	139.28 mm
Height	76.9 mm
Weight	500 g
Diameter	60.4 mm
