Network Camera User Manual
143
if in a live view or playback.
Display Target info. on Alarm Picture: There will be a frame on the target on
the uploaded alarm picture if the checkbox is checked.
Snapshot Setting: Select the picture quality for the captured picture. Good, better, and
best are selectable.
Background Upload: Check the checkbox of background upload if you want to upload
the background picture as well.
 Shield Region
The shield region allows you to set the specific region in which the face capture will
not function. Up to 4 shield regions are supported.
Steps:
1. Click the hexagons sign to draw shield area by left click end-points in the
live view window, and right click to finish the area drawing.
Notes:
● Polygon area (4~10 sides) sides is supported.
● Click to delete the drawn areas.
● If the live view is stopped, there is no way to draw the shield regions.
Draw Shield Area
2. Click Save to save the settings.
 Rule
Steps:

HIKVISION DS-2CD7126G0-IZS-B Specifications

General

Model	DS-2CD7126G0-IZS-B
Type	Network Camera
Image Sensor	1/2.8" Progressive Scan CMOS
Max Resolution	1920 × 1080
IR Range	Up to 30 m
Day/Night	ICR
Video Compression	H.265+/H.265/H.264+/H.264
Bit Rate	32 Kbps to 16 Mbps
Ingress Protection	IP67
Sensor Type	CMOS
Lens Type	Varifocal
Lens	Motorized zoom lens
Focal Length	2.8 mm to 12 mm
Minimum Illumination	0 Lux with IR
Network Interface	RJ45 (10/100Base-T)
Power Supply	DC12V ± 25%, PoE (802.3af)
Power Consumption	Max 10 W
Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Resolution	1920 x 1080
