HIKVISION DS-2CD883F-E User Manual

Quick Operation Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
14
1
10M/100M self-adaptive Ethernet interface
2
Power supply interface
3
IN, G: Alarm input interface
1A, 1B: Alarm output interface
4
D+, D-: RS-485 interface
5
AUDIO IN, G: Audio input interface
AUDIO OUT, G: Audio output interface
Camera wiring Diagram:
Figure 1-21 Wiring Diagram
1.4 Appearance Description of Cube Camera
1.4.1 Cube Camera I
Camera description:
Figure 1-22 Overview
1
2
4
5
3
6
7
8
9
10
11
