Quick Operation Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
IN, G: Alarm input interface
Note: The type of auto-iris interface is shown in Figure 1-2, and the definition of each pin is shown
below:
Figure 1-2 Auto-iris Interface
Table 1-2 Pins
Power, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+
and Drive- pins are used when the auto-iris is driven by DC.
Camera wiring Diagram:
Figure 1-3 Wiring Diagram
1.1.2 Box Camera II
Camera description:
