High-definition IR Water-proof Bullet Camera· User Manual
Manually set the shutter speed.
For PAL standard, 1/50, 1/120, 1/250,
1/500, 1/1K, 1/2K, 1/4K and 1/10K
(second) are selectable.
For NTSC standard, 1/60, 1/100, 1/250,
1/500, 1/1K, 1/2K, 1/4K and 1/10K
(second) are selectable.
The AGC value can be set as 6.00, 12.00,
18.00, 24.00, 30.00, 36.00, 42.00 or
44.8.
AUTO mode
In AUTO SETUP mode, the SHUTTER and AGC value will change
automatically according to the lighting environment, which can be
distinguished as LOW LUMINANCE and HIGH LUMINANCE.
Note: AGC is only available in LOW LUMINANCE condition.
AUTO SETUP
HIGH LUMINANCE
MODE SHUT+AUTO IRIS/AUTO IRIS
BRIGHTNESS ----|---- 080
LOW LUMINANCE
MODE AGC
BRIGHTNESS *0.50
RETURN
