High-definition IR Water-proof Bullet Camera· User Manual
There are MID, HIGH and LOW
selectable, standing for middle, high and
low luminance respectively.
There are MID, HIGH, LOW, MIDLOW and
MIDHIGH selectable.
4.8 Motion Detection Settings
Before you start:
There are two parts of MOTION DET configurations, BLOCK
DISP and MONITOR AREA. BLOCK DISP is to define motion
detection areas by predefined blocks; for MONITOR AREA, you
can set up to 4 areas with adjustable coordinators.
MOTION DET
DETECT SENSE ----|---- 111
BLOCK DISP OFF
MONITOR AREA ON
AREA SEL 1/4
TOP ----|---- 128
BUTTOM ----|---- 128
LEFT ----|---- 128
RIGHT ----|---- 128
RETURN
Figure 4-9 Motion Detection
BLOCK DISP
Steps:
