Color Zoom Camera· User Manual
9
9
Figure 2-5 DS-2CZ2152P-IRA wiring definition
Table 2-1 DS-2CZ2152P-IRA Interfaces Description
No.
Description
1
GND Interface
2
12V DC Power Supply
3
Zoom and Focus control interfaces
4
Video Output Interfaces
5
D+,D- Control Signal Input
