HIKVISION DS-2CZ2114P User Manual

Color Zoom Camera· User Manual
55
55
Table 6 DS-2CZ2182P-WD
Specification
Model
Parameter
DS-2CZ2182P-WD
30X CCD ICR Zoom Camera
Camera
Image Sensor
1/4" SONY Interline Transfer Super HAD-II CCD
Signal System
PAL
Effective Pixels
752 (H) × 582 (V)
Min. Illumination
Color: 0.2Lux @ (F1.6, AGC ON), 0.0008 Lux @
(F1.6, AGC ON, sensitivity × 256)
B/W: 0.02 Lux @ (F1.6, AGC ON), 0.00008 Lux
@ (F1.6, AGC ON, sensitivity × 256)
Shutter Time
1/50 to 1/10,000 s
Day & Night
IR cut filter auto switch
Horizontal Resolution
540TVL (Color), 600TVL (B/W)
Synchronization
Internal synchronization
Video Output
1 Vp-p composite output (75Ω/BNC)
S/N Ratio
More than 50dB
Lens
Focal Length
3.5-105.5 mm, 30X
Zoom Speed
Approx. 5 s (Optical, Wide-tele)
