HIKVISION DS-2DE5425IWG-4G User Manual

5.4 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background informaon is less focused.
5.4.1 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest,
thus to increase the quality of the ROI whereas the background
informaon is less focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to
Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select Stream Type.
4.
Select Region No. and click
to draw ROI region on the live view.
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
5.
Input the Area Name and ROI Level.
6.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
7.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
5.5 Display Info. on Stream
The informaon of the objects (e.g. human, vehicle, etc.) is marked in the video stream. You can
set rules on the connected rear-end device or client
soware to detect the events including line
crossing, intrusion, etc.
Before You Start
This funcon is supported in smart events. Go to VCA , select Smart Event and click Next to enable
Smart Event.
Steps
1.
Go to
Conguraon → Video/Audio → Display Info. on Stream .
Network Speed Dome User Manual
26

HIKVISION DS-2DE5425IWG-4G Specifications

General

Image Sensor	1/2.8" Progressive Scan CMOS
Max. Resolution	1920 × 1080
Lens	4.8 mm to 120 mm
Focal Length	4.8 mm to 120 mm
Digital Zoom	16x
IR Range	Up to 150 m
WDR	120 dB
Pan Range	360° endless
Tilt Range	-15° to 90° (auto flip)
Preset Positions	300
Working Temperature	-30°C to 65°C (-22°F to 149°F)
Protection Level	IP66
Ingress Protection	IP66
Video Compression	H.265+/H.265/H.264+/H.264/MJPEG
Camera Type	PTZ
Zoom	25x Optical
Min. Illumination	Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR
Pan Speed	0.1° to 200°/s
Tilt Speed	0.1° to 120°/s
Protocols	TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Ethernet Interface	RJ-45 10/100 Base-T
Audio Input	1 audio input
Audio Output	1 audio output
Alarm Input	2
Alarm Output	1
Power	PoE+ (802.3at, class 4)
Power Supply	PoE+ (802.3 at)
Power Consumption	Max. 20 W
Operating Conditions	Humidity: 90% or less (non-condensing)
Weight	3 kg (6.61 lb)
Frame Rate	50Hz: 25fps (1920 × 1080); 60Hz: 30fps (1920 × 1080)
Day/Night	IR cut filter
