HIKVISION DS-2TD4166-25/V2

User Manual of Thermal Bi-spectrum Network Speed dome
© Hikvision
119
Figure 7-52 Adjust OSD Location
7. Click to activate above settings.
7.4.3 Configuring Text Overlay Settings
Purpose:
You can customize the text overlay.
Steps:
1. Enter the Text Overlay settings interface:
Configuration > Image > OSD Settings
2. Check the checkbox in front of textbox to enable the on-screen display.
3. Input the characters in the textbox.
4. Use the mouse to click and drag the red text frame Text in the live view window to adjust the
text overlay position.
5. Click to save the settings.
7.4.4 VCA Rule Display
Purpose:
You can customize the VCA rule display information format.
Step:
Figure 7-53 VCA Rule Display
1. Set the font size of the VCA rules.
2. Customize the color of line and frame for Normal, Pre-Alarm, and Alarm.
3. Click to save the settings.
