Chapter 2 Installation
Please select the appropriate installation method according to the actual needs.
Before You Start
• Ensure that the desktop or rack is stable and firm enough.
• Keep the room well-ventilated. Keep at least 10 cm distance around the device for heat
dissipation.
• Keep at least 1.5 cm vertical distance between two adjacent devices for rack-mount installation.
2.1
Desk-Mounted Installation
Place the device on the desk.
2.2
Rack-Mounted Installation
Steps
1. Check the grounding and stability of the rack.
2. Use the attached screws to fix the two L-shaped brackets to the sides of the switch.
Figure 2-1 Fix L-Shaped Brackets
3. Place your switch on the rack, fix it to the rack with self-prepared screws to stably install your
switch.
Figure 2-2 Fix to the Rack
