Network Video Recorder User Manual
32
3. Go to Configuration → Record → Schedule.
4. Select recording type as Continuous. Refer to Edit Schedule for details.
Configure Event Recording
You can configure the recording triggered by the motion detection, line crossing detection, and
intrusion detection.
Steps
1. Go to Configuration → Event → Smart Event.
2. Configure the event detection and select the channels to trigger the recording when an event
occurs.
3. Go to Configuration → Record → Parameter.
4. Set the continuous main stream/sub-stream recording parameters for the camera. Refer to
Configure Recording Parameter for details.
5. Go to Configuration → Record → Schedule.
6. Select recording type as Event. Refer to Edit Schedule for details.
Edit Schedule
Steps
1. Go to Configuration → Record → Schedule.
Figure 5-11 Recording Schedule
Continuous
Continuous recording.
Event
Recording is triggered by events.
2. Select a camera in Camera No.
3. Turn on Enable.
