RTSP Authencaon
Two authencaon types are selectable, if you select digest, only the request with digest
authencaon can access the video stream by the RTSP protocol via the IP address. For
security reasons, it is recommended to select digest as the authencaon type.
ISAPI
ISAPI (Internet Server Applicaon Programming Interface) is an open protocol based on HTTP,
which can realize the
communicaon between the system devices (e.g., network camera,
NVR, etc.). The video recorder is used as a server, the system can nd and connect the video
recorder.
HTTP
The admin user account can disable the HTTP service from the GUI or the web browser. Aer
the HTTP is disabled, all the related services, including ISAPI and ONVIF, will terminate as
well.
HTTP Authencaon
If you need to enable the HTTP service, you can set the HTTP authencaon to enhance the
access security. Two authencaon types are selectable. For security reasons, it is
recommended to select digest as the
authencaon type.
Camera Added Detecon
The funcon detects the network camera status. If the network camera has been added by
another video recorder, the network camera status will show as in Online Device list.
5. Click Apply.
7.4 Upgrade
Warning
Do not shutdown or turn o the power during upgrade.
7.4.1 Local Upgrade
Before You Start
Store the upgrade rmware to a backup device, and connect it to your device.
Steps
1. Go to Maintenance .
2. Click
near Firmware.
3. Go to Local Upgrade .
4. Select a backup device in Device Name.
5. Select the upgrade
rmware.
6. Click Upgrade. Your device will reboot automacally.
Network Video Recorder User Manual
71

HIKVISION DS-7104NI-Q1 Specifications

General

Certification	FCC 15 B, ANSI C63.4-2014 CE EN50130-4, EN 61000-3-2, EN 61000-3-3
Product color	Black
Output current	1 A
Output voltage	48 V
Power consumption (typical)	10 W
Total Power over Ethernet (PoE) budget	36 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
HDD capacity	0 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	6 TB
Number of HDDs installed	0
Number of HDDs supported	1
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	5
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Power over Ethernet (PoE) ports quantity	4
Video codecs	H.265+/H.265/ H.264+/H.264
Input bandwidth	40 Mbit/s
Output bandwidth	60 Mbit/s
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Wi-Fi	No

Weight and Dimensions

Depth	225 mm
Width	265 mm
Height	48 mm
Weight	1000 g
