HIKVISION DS-7108HI-S Series Technical Manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4. Specifications
Model
DS-7108HI-S
Compression
standard
H.264
Preview resolution
PAL: 704*576 (4CIF) NTSC: 704*480 (4CIF)
Recording
resolution
CIF/QCIF
Video input
8 channels BNC ( 1.0Vp-p ,75 Ohm)
Video out
1 channel BNC (1.0Vp-p ,75 Ohm)
Video spot out
1 channel BNC (1.0Vp-p ,75 Ohm)
Video loop out
8 channels
Frame rate(per
channel)
CIF: 25(P)/30(N)
Audio compression
standard
OggVorbis, 16Kbps
Audio in
4 channels RCA (2Vp-p ,1KOhm)
Audio out
1 channel RCA (Linear electrical level, 600 Ohm)
Voice talk
1 channel (Using 1st channel of Audio IN)
Stream type
Video/Video & Audio
Support dual
stream
Yes
Bit rate
32Kbps~2Mbps, or user-defined (Max. 8Mbps)
SATA interface
2 SATA interface , support 2 SATA HDDs. Each supports up
to 2TB.
Network port
10M/100M adaptive Ethernet interface
RS-232 port
1 DB9 port
RS485 port
1, T+T- R+R-
USB
1 USB 2.0 interface, support USB mouse, support USB disk,
USB HDD, USB CD/DVD-R/W
VGA Interface
1VGA resolution:
800*600/60Hz
800*600/75Hz
1024*768/60Hz
Alarm in
16 channels
Alarm out
4 channels
Power supply
DC 12V
Power
consumption
≤30W(without HDDs)
Working
-10°C~+55°C

HIKVISION DS-7108HI-S Series Specifications

General

Brand	HIKVISION
Model	DS-7108HI-S Series
Category	DVR
Language	English
