Product Key Features
General
Support HD-SDI camera connection;
Each channel supports dual-stream. Main stream supports up to 1080P resolution and sub-stream
supports up to 4CIF resolution;
Independent configuration for each channel, including resolution, frame rate, bit rate, image quality,
etc.
Encoding for both video stream and video & audio stream; audio and video synchronization during
composite stream encoding;
Watermark technology;
Local Monitoring
Simultaneous HDMI, VGA and CVBS outputs (no CVBS output for DS-7200HFHI-SL,
DS-7200HFHI-SE and DS-7200HFHI-ST);
HDMI output and VGA output at up to 1920*1080 resolution.
1/4/6/8/9/16 screen live view is supported, and the display sequence of screens is adjustable.
Live view screen can be switched in group and manual switch and automatic cycle live view are also
provided, the interval of automatic cycle can be adjusted.
Quick setting menu is provided for live view.
The selected live view channel can be shielded.
Motion detection, video-tampering detection, video exception alarm and video loss alarm functions.
Privacy mask;
Several PTZ protocols supported; PTZ preset, patrol and pattern.
Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse;
HDD Management
For DS-7200HFHI-SL series, 1 SATA hard disk can be connected; for DS-7200HFHI-SE and
DS-7200HFHI-ST series, up to 2 SATA hard disks can be connected; for DS-7300HFHI-ST series, 4
SATA hard disks and 1 eSATA disk can be connected; and for DS-8100HFHI-ST series, 8 SATA hard
disks and 1 eSATA disk can be connected. (Each disk with a maximum of 4TB storage capacity.)
8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.
Support eSATA disks for recording or backup.
Support S.M.A.R.T. and bad sector detection.
Support HDD standby function;
HDD property: redundancy, read-only, read/write (R/W).
HDD group management;
HDD quota management; different capacity can be assigned to different channels.
Recording and Playback
Holiday recording schedule configuration;
Cycle and non-cycle recording modes;
Normal and event video encoding parameters;
Multiple recording types: manual, normal, alarm, motion, motion | alarm, motion & alarm;
8 recording time periods with separated recording types;
Pre-record and post-record for motion detection triggered recording, and pre-record time for schedule
