Quick Operation Guide of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR
21
Table 17 Specifications for DS-7300HFI-SH
Model
DS-7304
HFI-SH
DS-7308
HFI-SH
DS-7316
HFI-SH
DS-7324
HFI-SH
DS-7332
HFI-SH
Video/Audio input
Video compression H.264
Analog video input 4-ch 8-ch 16-ch 24-ch 32-ch
IP video input
1-ch 2-ch 2-ch -- --
Up to 720P
resolution
Up to 1080P resolution
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression G.711u
Audio input 4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot out
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 2-ch, RCA (Linear, 600 Ω)
Audio bit rate 64 Kbps
Dual-stream Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Video,
Video &
Audio
Channel 1-4: Video, Video & Audio;
Other channels: Video
Synchronous
playback
4-ch 8-ch 16-ch
Hard disk
SATA 4 SATA interfaces for 2HDDs + 1 DVD-R/W (default), or 4 HDDs
eSATA 1 eSATA interface
Capacity Up to 4TB capacity
External interface
Network interface 1, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface
1 RS-232,
RS-485(half-duplex),
Keyboard
1 RS-232,
RS-485(full-duplex),
Keyboard
USB interface 3 × USB 2.0
Alarm in 4 8 16 16
Alarm out 1 4 4 8
General
Power supply 100~240VAC, 5A, 50~60Hz
Consumption
(without HDD or
DVD-R/W)
≤ 25 W ≤ 30 W ≤ 35 W ≤ 40 W
Working temperature -10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 1.5U chassis
Dimensions
(W × D × H)
445 × 390 × 70 mm
Weight
(without HDD or
DVD-R/W)
≤ 5 kg
