Quick Operation Guide of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR
22
Table 18 Specifications for DS-7300HWI-SH
Model
DS-7304
HWI-SH
DS-7308
HWI-SH
DS-7316
HWI-SH
DS-7324
HWI-SH
DS-7332
HWI-SH
Video/Audio
input
Video compression H.264
Video input 4-ch 8-ch 16-ch 24-ch 32-ch
IP video input
1-ch 2-ch 2-ch -- --
Up to 720P
resolution
Up to 1080P resolution
Video input
interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression G.711u
Audio input 4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot out
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 2-ch, RCA (Linear, 600 Ω)
Audio bit rate 64 Kbps
Dual-stream Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Video,
Video &
Audio
Channel 1-4: Video, Video & Audio;
Other channels: Video
Synchronous
playback
4-ch 8-ch 16-ch
Hard disk
SATA 4 SATA interfaces for 2HDDs + 1 DVD-R/W (default), or 4 HDDs
eSATA 1 eSATA interface
Capacity Up to 4TB capacity for each disk
External interface
Network interface 1, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface 1 RS-232, RS-485(half-duplex), Keyboard
1RS-232,RS-485(full-duplex)
Keyboard
USB interface 3 × USB 2.0
Alarm in 4 8 16 16
Alarm out 1 4 4 8
General
Power supply 100~240VAC, 5A, 50~60Hz
Consumption
(without HDD or
DVD-R/W)
≤ 25 W ≤ 30 W ≤ 35 W ≤ 40 W
Working
temperature
-10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 1.5U chassis
Dimensions
(W × D × H)
445 × 390 × 70 mm
Weight
(without HDD or
DVD-R/W)
≤ 5 kg

HIKVISION DS-7208HWI-SH Specifications

General

Product color	Black
USB connectivity	Yes
Channels quantity	8 channels
Video capturing speed	30 fps
Total storage capacity	8000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768
Display resolution	960 x 576 pixels
BNC input ports	8
BNC output ports	1
USB 2.0 ports quantity	2
Ethernet interface type	Fast Ethernet
Supported network protocols	NTP, SMTP, NFS, UPnP, iSCSI
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power requirements	12 VDC
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 290 x 45 mm
