Digital Video Recorder User Manual
189
10.15 Sudden Scene Change
Purpose
Scene change detection function detects the change of surveillance environment affected by the
external factors; such as the intentional rotation of the camera and some certain actions can be
taken when the alarm is triggered.
Please refer to the Chapter 10.1 Face Detection for operating steps to configure the scene
change detection.
The Sensitivity in the Rule Settings ranges from 1 to 100, and the higher the value is, the
more easily the change of scene can trigger the alarm.
For the analog cameras, the line crossing detection and intrusion detection conflict with
other VCA detection such as sudden scene change detection, face detection and vehicle
detection. You can only enable one function. If you have enabled line crossing detection or
intrusion detection, when you enable sudden scene change detection and apply the
settings, the following attention box pops up to remind you there is no enough resource
and ask you to disable the enabled VCA type(s) of the selected channel(s).
Figure 10-12 Disable Other VCA Type(s)
10.16 PIR Alarm
Purpose
A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector's field of
view. The heat energy dissipated by a person, or any other warm blooded creature such as dogs,
cats, etc., can be detected.
Step 1 Enter the VCA settings interface.
Menu> Camera> VCA
Step 2 Select the camera to configure the VCA.
You can check the checkbox of Save VCA Picture to save the captured pictures of VCA
detection.
Step 3 Select the VCA detection type to PIR Alarm.
