HIKVISION DS-7216HQHI-F2/N User Manual

Digital Video Recorder User Manual
272
Each two video channels are grouped in sequence, e.g., CH01 and CH02, CH03 and CH04...; and
each two channels in the same group must be connected with the same type of video source
(Turbo HD or CVBS). The above information is for reference only. Please refer to the specific
configuration of the device.
SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA 2 SATA interfaces
Capacity Up to 6 TB capacity for each disk
External
interface
Network interface 1, 10M/100M self-adaptive Ethernet interface
USB interface 2 × USB 2.0
General
Power supply 12 VDC
Consumption
(without HDD)
≤ 12 W ≤ 20 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working humidity 10% to 90%
Dimensions
(W × D × H)
380 × 320 × 48 mm (14.9 × 12.6 × 1.9 inch)
Weight
(without HDD)
≤ 2 kg (4.4 lb)

HIKVISION DS-7216HQHI-F2/N Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Rack capacity	1U
Channels quantity	16 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	16
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (max)	30 W

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	380 x 320 x 45 mm
