HIKVISION DS-7600 Series Quick Start Guide

3. Startup and Shutdown (cont.)
To shutdown your DVR:
OPTION 1: Standard Shutdown
1. Enter the Shutdown menu by going to Main Menu >
Maintenance > Shutdown.
2. Select the Shutdown button.
3. Click the Yes button.
OPTION 2: Manual Shutdown
1. Press and hold the POWER button for 3 seconds.
2. Enter the administrator's username and password
in the dialog box for authentication.
3. Click the Yes button.
NOTE: Do not press the POWER button again
when the system is shutting down.
4. Formatting a Disk
A newly installed hard disk drive (HDD) must be formatted first before it can be used with your DVR.
NOTE: Formatting the disk will erase all data on it.
To format a new disk:
1. Enter the Disk Management menu by going to Main Menu > System Configuration
> Disk Management.
2. Select a disk to format. A disk that has not been formatted will show Error Detected as its status.
If the disk is one that is newly installed, the status of the drive will show up as Non-Active and the
Reformat button will change to the Add button.
NOTE: One hard disk drive (HDD) is already installed and formatted in this DVR.
First Choice For Security Professionals

HIKVISION DS-7600 Series Specifications

General

Video Output	BNC
Compression	H.264
Network Interface	RJ-45
USB Interface	2 × USB 2.0
VGA Output	1 channel, up to 1920x1080 resolution
Operating Temperature	-10 °C ~ +55 °C (14 °F ~ +131 °F)
Operating Humidity	10% ~ 90%
