HIKVISION DS-7600 Series Quick Start Guide

4. Formatting a Disk (cont.)
3. Click the Add button.
4. A confirmation message will appear on the screen.
Click the Yes button to continue formatting process.
5. A format progress bar will be shown on the menu.
After the disk has been formatted, the status of the
disk will change to Active.
6. Click the Done button to exit out of Disk Management.
5. Setting Date & Time
1. Enter the Time/Date menu by going to Main Menu
> System Configuration > Time/Date.
2. Enter the correct date and time.
3. Click the Save button to save the setting.
To setup date and time:
HYBRID DVR/NVR/ANALOG

HIKVISION DS-7600 Series Specifications

General

Video Output	BNC
Compression	H.264
Network Interface	RJ-45
USB Interface	2 × USB 2.0
VGA Output	1 channel, up to 1920x1080 resolution
Operating Temperature	-10 °C ~ +55 °C (14 °F ~ +131 °F)
Operating Humidity	10% ~ 90%
