Network Video Recorder User Manual
192
Figure 12. 8 Create Array Interface
3. Edit the Array Name; set the RAID Level to RAID 0, RAID 1, RAID 5, RAID6 or RAID 10; select the
Physical Disk that you want to configure array.
If you choose RAID 0, at least 2 HDDs must be installed.
If you choose RAID 1, 2 HDDs need to be configured for RAID 1.
If you choose RAID 5, at least 3 HDDs must be installed.
If you choose RAID 6, at least 4 HDDs must be installed.
If you choose RAID 10, the number of HDDs installed should be even in the range of 4 to 16.
4. Click OK button to create array.
If the number of HDDs you select is not compatible with the requirement of the RAID level, the error message box
will pop up.
Figure 12. 9 Error Message Box
5. You can click Array tab to view the successfully created array.
Figure 12. 10 Array Settings Interface
