HIKVISION DS-7600NI-K1 Series - Rear Panel; DS-9600 NI and DS-8600 NI Series

Network Video Recorder User Manual
25
1.5 Rear Panel
1.5.1 DS-9600NI and DS-8600NI Series
Figure 1. 7 DS-9600NI-I8 and DS-8600NI-K8 Series
Figure 1. 8 DS-9600NI-I16 Series
Table 1. 5 Panel Description
No.
Name
Description
1
LAN1/LAN2 Interface
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces provided.
2
LINE IN
RCA connector for audio input.
3
AUDIO OUT
2 RCA connectors for audio output.
4
HDMI1/HDMI2
HDMI video output connector.
5
VGA1/VGA2
DB9 connector for VGA output. Display local video output and menu.
6
USB 3.0 interface
Universal Serial Bus (USB) ports for additional devices such as USB
mouse and USB Hard Disk Drive (HDD).
7
RS-232 Interface
Connector for RS-232 devices.
8
eSATA
Connects external SATA HDD, CD/DVD-RM.
9
Controller Port
D+, D- pin connects to Ta, Tb pin of controller. For cascading devices,
the first NVR’s D+, D- pin should be connected with the D+, D- pin of
the next NVR.
ALARM IN
Connector for alarm input.
ALARM OUT
Connector for alarm output.
