Network Video Recorder User Manual
36
3. After the time settings, click Next button which takes you back to the Network Setup Wizard window, as
shown in the following figure.
Figure 2. 13 Network Setting
Two self-adaptive 10M/100M/1000M network interfaces provided for DS-9600NI, DS-8600NI, DS-7700NI-I4 and
DS-7700NI-K4, and two working modes are configurable: multi-address and network fault tolerance. And one
self-adaptive 10M/100M/1000M network interface for DS-7600NI, DS-7700NI-I4/P and DS-7700NI-K4/P.
4. Click Next button after you configured the basic network parameters. Then you will enter the HIK Cloud
P2P interface. Configure the HIK Cloud P2P according to your need.
Figure 2. 14 Advanced Network Parameters
5. Click Next button after you configured the basic network parameters. Then you will enter the Advanced
Network Parameter interface. You can enable UPnP, DDNS and set other ports according to your need.
