Network Video Recorder User Manual
159
8.6 Setting Alarm Response Actions
Purpose:
Alarm response actions will be activated when an alarm or exception occurs, including Event Hint
Display, Full Screen Monitoring, Audible Warning (buzzer), Notify Surveillance Center, Trigger
Alarm Output and Send Email.
Event Hint Display
When an event or exception happens, a hint can be displayed on the lower-left corner of live view
image. And you can click the hint icon to check the details. Besides, the event to be displayed is
configurable.
Step 1 Enter the Exception settings interface.
Menu > Configuration > Exceptions
Step 2 Check the checkbox of Enable Event Hint.
Figure 8-14 Event Hint Settings Interface
Step 3 Click the to set the type of event to be displayed on the image.
Figure 8-15 Event Hint Settings Interface
Step 4 Click the OK button to finish settings.
Full Screen Monitoring
When an alarm is triggered, the local monitor (VGA, HDMI or BNC monitor) display in full screen
the video image from the alarming channel configured for full screen monitoring.
To Next Page
